Rosta Rubber Suspension Units DO-A

The housing up to 45 size of Rubber Suspension Units DO-A are made from light alloy profile, size 50 is made out of spheroidal graphite cast iron, inner square section - light alloy profile with four ''throughbores''.

The unit levers can be mounted on one or both sides by means of bolts. It provides an excellent attachement without movement, which is very essential in order to transmit alternating motions passing the neutral axis in either direction. All metal parts are paint-finished







General Catalog

Rosta Technologies






MPN:01 041 001


Specifications


Weight (kg)

0.1

Type

15 x 25

øA

5

B

10

D

28

E

25.5

F

53.5

S

15

G

-

L

25

H

-

L1

30

Please Note: Photo may not represent actual item, please refer to title and product specifications for all details.

Rosta Rubber Suspension Units DO-A

MPN: 01 041 001
